Vacuum Cleaners Hammers Power Tool Armature Winder For Slot Type Commutator

: Large Image : Vacuum Cleaners Hammers Power Tool Armature Winder For Slot Type Commutator

Product Details:

Place of Origin:	Chinese machine for producing electric motor armature
Brand Name:	Wind Automation
Certification:	Custom made machine for many developed and developing countries
Model Number:	armature winding, welding,shaft insertion, stator winding,

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	USD
Packaging Details:	Polywood case
Delivery Time:	25 working days

Contact Now

Detailed Product Description

Vacuum Cleaners Hammers Power Tool Armature Winder For Slot Type Commutator Advantages:
1. Slot type armature with thin, thick wire machine can handle,
Machine had good feedback of winding a 0.25mm wire diameter armature
2. Have good adaption for slot type commutator with groove,
No need to work with special designated slot machine
3. Got good feedback in wide application from customers
4. 98% yield rate above assured when the slot commutator quality is good
5. Till now it is the best machine in China for winding slot type armature

Video:

https://youtu.be/B3qWEeS4l2M
https://vimeo.com/148309838

Main data:
Wire diameter: 0.20~1.2mm
Armature diameter range:20~90mm
Armature stack length:10~130mm
Commutator diameter:8~60mm
Armature slot number:Odd, oven slot
Turns no.:0~99999
Flier fork speed:0~2000RPM
Indexing speed:0~2500RPM
Total power:4.5KW
Operation method:Step, Auto, JOG
Power source:AC380V 50/60Hz
Air source:5~7KG/cm2
Weight:850KGS
Dimension:1530mm x 1280 mm x 1650mm
