Stator Powder Coating Machine For Motor Insulation Electrostatic Coating

China Stator Powder Coating Machine For Motor Insulation Electrostatic Coating supplier

Large Image :  Stator Powder Coating Machine For Motor Insulation Electrostatic Coating

Product Details:

Place of Origin: Chinese machine for producing electric motor
Brand Name: Wind Automation
Certification: Custom made machine for many developed and developing countries
Model Number: stator winding, armature winding, welding

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: USD
Packaging Details: Polywood case
Delivery Time: 45 working days
Payment Terms: T/T, L/C,
Detailed Product Description

Stator Powder Coating Machine For Motor Insulation Electrostatic Coating


This series electro static powder coating machine is the most advanced technology product in electrostatic coating field, which is widely used in micro rotor insulating coating, such as automotive, motorcycle, electric bicycle, toy and small electromotor of home appliances.
Stator Powder Coating Machine For Motor Insulation Electrostatic Coating
Stator Powder Coating Machine For Motor Insulation Electrostatic Coating

Its working process: rotor is transferred to fluidizing bed by screw for coating. Isolation power is evenly coated on its surface, and then cured by high frequency heating. Video film for window lifer armature production
It is composed of pre-heating zone, cooling zone, coating zone and curing zone.
Parameter:
Armature OD: by customer drawing
Core length: by customer drawing
Shaft length: by customer drawing
Output: by customer request
Coating thickness: 0.15-0.5mm adjustable
Armature transfer speed: 0.1-15.meters per minute




Model

100

80GG

80GD

50H

Lab model


note

Part size

Max OD

160

120

120

100

200

Is able to be tailored produced

Max core length

50

50

50

50

80

Max shaft length

180

180

180

180

180

transfer speed m/min

0.1-1.5

0.1-1.5

0.1-1.5

0.1-1.5

Electronic driving

Stepless adjustable

output(pc/h)

2500

1500

1500

800

10-60

фMax≤20mm

Curing method


High frequency


High frequency


  High frequency

Curing oven


Curing
oven

Oven is prepared by customer

Coating thickness(mm)

Adjustable within 0.15-0.5



Above parameter is only for reference
