Commutator Rotor Precise Turning Machine Lathe Commutator China Cheap Machine

China Commutator Rotor Precise Turning Machine Lathe Commutator China Cheap Machine supplier
Commutator Rotor Precise Turning Machine Lathe Commutator China Cheap Machine supplier Commutator Rotor Precise Turning Machine Lathe Commutator China Cheap Machine supplier Commutator Rotor Precise Turning Machine Lathe Commutator China Cheap Machine supplier Commutator Rotor Precise Turning Machine Lathe Commutator China Cheap Machine supplier

Large Image :  Commutator Rotor Precise Turning Machine Lathe Commutator China Cheap Machine

Product Details:

Place of Origin: Chinese machine for producing electric motor
Brand Name: Wind Automation
Certification: Custom made machine for many developed and developing countries
Model Number: stator winding, armature winding, welding

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: USD
Packaging Details: Polywood case
Delivery Time: 25 Working days
Contact Now
Detailed Product Description
X,Y Axis: With Servo Device And Touch Screen Turning Material: Commutator Copper Or Rotor Aluminum
Turning Belt: Different Turning Belt For Commutator OD And Rotor OD Can Install Setting: Can't Install Setting Because Cutter Initial Positiong Is Needed

Washing Machine Induction Motor Rotor Outside Diameter Armature Surface Turning WIND-CT-TH3







Application:



The lathe turning machine WIND-CT-TH3 is precision equipment for turning the external OD of coomutator



or the excircle of rotor iron cores







Competitive Advantages:



1.Advanced design, appealing design and excellent performance



2. One servo control the turning



3. Main parts adopt imported prats



4. Machine have high efficiency and strong rliability







Specification:



Roundness: ≦0.003mm
Surface roughness: ≦Ra0.40
Rotor outer diameter: Ф20-Ф100mm
Rotor shaft length: 32-250mm
Rotor shaft diameter: Ф3-Ф22mm
Commutator outer diameter: Ф4.3-Ф50mm
Turning capability: rough turning Max0.20mm diameter
Speed amplitude modulation: 0-60Hz
Feeding unit: 1μm-0.5mm arbitrary
Cutting length: Max80mm
Feeding speed: Stepless adjustable
Control mode: stepping, automatic
Operation method: Touch screen operation
Air source pressure: 5-7kg/cm²
Turning times: 1-4 Any setting
Fixture: Diamond V-shaped Frame
Total power: 2.5Kw
Power source: AC220V 50/60Hz
Weight: about 500Kg
Dimensions: 1100×850×1800mm³







Diamond Turning Tool advantages:





1. Comapring to Alloy CNC turning tool (carbide), turning machine's diamond tool is advanced,



Diamond turning tool is what most Chinese motor manufacturers are using as diamond tool



can achieve better shining and micro finish after lathing and turning the copper surface



Alloy CNC turning tool carbide is only suitable for aluminum iron alloy surface product turning





2. The holding device of turning machine WIND-CT-TH3B for holding your Rotor OD have



two side ball bearing device which prevent shaft from wear





3. There was a German customer who used this device for over 10year in German and Austria,



and still purchase the diamond turning tool from us





Commutator Rotor Precise Turning Machine Lathe Commutator China Cheap Machine



The lathe machine is designed to finish turn the rotor outside diameter and commutator brush track



area of relatively small fractional horsepower motor armatures, starter armatures commutator,



Turning of the commutator brush track area is accomplished through the use of a diamond-tipped



tool mounted onto a precision machine slide driven by a Delta A.C. servo motor,



turning and milling the surface of aluminum rotor and commutator copper to let it polish and shining,
