Armature Rotor Stacks Electrostatic Powder Coating Machine Working 10Years For Motor Manufacturers

: Large Image : Armature Rotor Stacks Electrostatic Powder Coating Machine Working 10Years For Motor Manufacturers

Product Details:

Place of Origin:	Chinese machine for producing electric motor
Brand Name:	Wind Automation
Certification:	Custom made machine for many developed and developing countries
Model Number:	WIND-JF-98GG

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	USD
Packaging Details:	Polywood case
Delivery Time:	45 working days
Payment Terms:	T/T, L/C,

Contact Now

Detailed Product Description

Application:	Motor Rotor Armature Insulating Coating	Material:	Curing Oven

This series electro static powder coating machine is the most advanced technology product in electrostatic coating field, which is widely used in micro rotor insulating coating, such as automotive, motorcycle, electric bicycle, toy and small electromotor of home appliances.
Armature Rotor Stacks Electrostatic Powder Coating Machine Working 10Years For Motor Manufacturers

Its working process: rotor is transferred to fluidizing bed by screw for coating. Isolation power is evenly coated on its surface, and then cured by high frequency heating. Video film for window lifer armature production
It is composed of pre-heating zone, cooling zone, coating zone and curing zone.
Parameter:
Armature OD: by customer drawing
Core length: by customer drawing
Shaft length: by customer drawing
Output: by customer request
Coating thickness: 0.15-0.5mm adjustable
Armature transfer speed: 0.1-15.meters per minute

Model		100	80GG	80GD	50H	Lab model	note
Part size	Max OD	160	120	120	100	200	Is able to be tailored produced
	Max core length	50	50	50	50	80
	Max shaft length	180	180	180	180	180
transfer speed m/min		0.1-1.5	0.1-1.5	0.1-1.5	0.1-1.5	Electronic driving	Stepless adjustable
output(pc/h)		2500	1500	1500	800	10-60	фMax≤20mm
Curing method		High frequency	High frequency	High frequency	Curing oven	Curing oven	Oven is prepared by customer
Coating thickness(mm)		Adjustable within 0.15-0.5

Above parameter is only for reference

Video:
https://vimeo.com/144614641

Tag:

Contact Person: Ms. Emily

Tel: 86-21-58992293
