Stator polyester film insulation paper forming machine for Two pole stator Slot liners

China Stator polyester film insulation paper forming machine for Two pole stator Slot liners supplier
Stator polyester film insulation paper forming machine for Two pole stator Slot liners supplier Stator polyester film insulation paper forming machine for Two pole stator Slot liners supplier

Large Image :  Stator polyester film insulation paper forming machine for Two pole stator Slot liners

Product Details:

Place of Origin: Chinese plant motor manufacturing Slot insulation
Brand Name: Wind Automation
Model Number: WIND-SCF polyester film paper forming slot liners and slot wedges

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: USD
Delivery Time: 45 days
Payment Terms: T/T, L/C,
Contact Now
Detailed Product Description
Motor Insulation Machine: 2pole Stator Polyester Film Insulation Paper Forming Machine

Stator polyester film insulation paper forming machine for Two pole stator Slot liners Form and cut the insulation paper for universal motor stator, cell insulation such as mixer,grinder,power tools,

Stator polyester film insulation paper forming machine for Two pole stator Slot liners

Stator polyester film insulation paper forming machine for Two pole stator Slot liners



Main technical data:

Armature O.D: Ф20-55mm

Length of lamination: Max 60mm

Parameter:

Shaft length: 32~250mm

Shaft O.D: Ф6~Ф20mm

Slot number: 8-24 slots

Commutator O.D: Ф16~Ф50mm

Speed regulation range: 0~60Hz

Length of insulation paper: 15-60mm adjustable

Thickness of insulation paper: 0.1 mm ~ 0.5 mm

Type of insulation material: DMD, DM, Polyester film(thickness 0.125mm), etc.

Insulation paper shape: V or edge-folding V

Efficiency: 0.5sec - 0.8sec/per slot, loading

Universal motor two pole stator paper forming machine working film
