Electric motor generator alternator stator testing machine judging equipment Dispositivos Testador

China Electric motor generator alternator stator testing machine judging equipment Dispositivos Testador supplier
Electric motor generator alternator stator testing machine judging equipment Dispositivos Testador supplier Electric motor generator alternator stator testing machine judging equipment Dispositivos Testador supplier

Large Image :  Electric motor generator alternator stator testing machine judging equipment Dispositivos Testador

Product Details:

Place of Origin: Chinese machine for producing starter electric motor
Brand Name: Wind Automation
Certification: test the stator
Model Number: WIND-DTS-120 Double position stator testing machine

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: Test the motor stators
Delivery Time: 45 working days
Supply Ability: test the stators
Contact Now
Detailed Product Description
Electric Motor Alternator Stator Testing: Suitable For Detection Of Small Inductive Stators Judge: Judging The Quality Of Generator Alternator 5 Items



Electric motor generator alternator stator testing machine Advantage:

Double position test in turn, the shortest test time can be up to 5 s/pc.



Testing item and accuracy:

1. DC Cooling state resistance test

Test method :Four points,with auto correctting ambient temperature function,

the standard temperature can be set, wire connection  according to buyer’s requirement.

Test range: 0.01Ω--1000Ω

Test tolerance: ±0.5%



2. Dielectric strength

Pass high voltage between phases

Test condition: AC 100V-3000V  adjustable.

Voltage tolerance : ±2.5%

current leakage range : 0.1-20mA

Current tolerance: ±1%

Time: 1sec~10sec(software setting)



3. Insulation Resistance

Test condition: DC 500V / 1000V

Range: 1MΩ~1000MΩ

Tolerance: ±2.5%,



4. Turn to Turn Insulation

Test condition: Taking a qualified stator as the standard sample, and save its test curve and data in computer. Then comparing the values of standard one and the to-be-tested stator, calculating the area and the relative error value of frequency , and then figure out the upper limit value of relative error value.

Pulse voltage peak value: 100V-3000V

Pulse peak value tolerance: ±2.5%

Suitable for detection of small inductive stators

Criterion value setting: conclude as per the percentage of △S and △f, setting range is 1%-99%



5. Balance of resistance

Determine the balance of resistance between coils



HS Code:9030390000



New energy drive motor generator stator testing Video: https://youtu.be/TP1OS69siOo
