Slot Paper Insertion For Single Three Phase AC Motor Stators

China Slot Paper Insertion For Single Three Phase AC Motor Stators supplier

Large Image :  Slot Paper Insertion For Single Three Phase AC Motor Stators

Product Details:

Place of Origin: Chinese machine for producing electric motor
Brand Name: Wind Automation
Model Number: WIND-160-SI slot insulation for big AC motor

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Detailed Product Description

Insert insulation paper polyester to stator's slot to insulate the stator stack and winding.

Alta eficiencia, tecnología avanzada, estable performance.Help a reducir costes mientras mantienen la alta calidad



Laminated thickness of stator

Lamina espessura: 10mm-60mm

Max outer diameter of stator: Φ 160mm
Diameter of stator: Φ 40mm- Φ 80mm
Height of edge folded: 2.5mm-4mm
Max insulation paper's thickness: 0.35mm
Feeding length: 12mm-45mm
Tack time: 0.5-0.7s/slot
Input: 380V/50Hz
Power: 0.75KW
Machine productivity: around 1500pcs/8hours
Dimension: 1150mm × 1000mm × 1500mm

Weight: ≈ 400kg



Video:

https://vimeo.com/125464089





Automatic Stator Paper Insertion Machine For Induction Motor Manufacturing

Automatic Stator Paper Insertion Machine for Induction Motor Manufacturing

This machine is suitable for small size stator with OD within 190mm.

(1) Specification

Stack length 20~160mm
Stator ID 50~120mm
Stator OD Max 190mm
Cuff height 2~4mm/4~7mm
Paper thickness 0.188~0.35mm
Cycle time 0.8 s/slot
Power supply 380V 50/60HZ
Weight 250KG
Dimension 1200x650x1200mm


(2) Feature
Manual loading and unloading
Parameter of different models can be edited, modified and displayed

Quick and easy readjustment for other types of stator
After paper inserted, no deformation of stator or lamination
Easy for operation, No skilled operator requiredLow noise, high efficiency
Production capacity ≤1s/slot (exclude the loading/unloading time)
Can be customized accordingly
High quality level of the paper inserting process
High repeatability of the insulation's shape and length


(3) Application
This machine is suitable for small and medium-sized three phase motor, single phase motor, external rotor motor and generator.
Automatic Stator Paper Insertion Machine for Induction Motor ManufacturingAutomatic Stator Paper Insertion Machine for Induction Motor Manufacturing
Automatic Stator Paper Insertion Machine for Induction Motor Manufacturing
