Home ProductsStator Winding machine

Muti pole stator winding amchine BLDC stator winder

We are very happy with the machines!

—— Efrain.Alvarado

We trust you and have very good references of you from our Shanghai colleagues

—— Olayo Delgado

Thank you so much!

—— Alain Vadrot

I think the segments look great, excellent layering

—— Paul

I'm Online Chat Now

Muti pole stator winding amchine BLDC stator winder

China Muti pole stator winding amchine BLDC stator winder supplier
Muti pole stator winding amchine BLDC stator winder supplier Muti pole stator winding amchine BLDC stator winder supplier

Large Image :  Muti pole stator winding amchine BLDC stator winder

Product Details:

Place of Origin: BLDC stator winding machine China supplier
Brand Name: Wind Automation
Model Number: Muti pole stator winding muti arms stator winder

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: USD
Packaging Details: Polywood case
Delivery Time: 45 working days
Payment Terms: T/T, L/C,
Supply Ability: Per customer's stator winding diagram
Detailed Product Description

Wind the stator with 6 poles, 9 poles, 12 poles, 18 poles and other muti pole stators

Muti pole stator winding amchine BLDC stator winder

Feature:

BLDC stator winder produce multi poles stator with 3nozzles(needles), winding trace is rectangle,

Parameter:

Wire diameter: 0.08~0.70mm

Stator ID:19~65mm

Stack height:7-90mm

Turns No.0-99999

Operation option: stepping/Auto

Stator poles: 6 poles, 9 poles, 12 poles, 18 poles (Customized)

Air pressure:5~7kg/square centi-meter

Power:2KW, AC220V 50/60Hz

Weight: about 450kgs Dimension: 1600(L)x1100(W)x1400(H)mm
